Completed development of new PQ inductor.

Date : 2024-05-02 Hit : 36

페이지 정보

본문

PQ inductors made of ferrite are already widely used in various fields in the global market.  Our company's PQ2915 inductor is our main product and is sold for automotive electronics, but we recently reduced the size of the product and launched the PQ2016 inductor, which has high Irms characteristics. Compared to the PQ2915 inductor product currently on sale, the PQ2016 inductor has reduced the size by more than 20%, lowered the Isat characteristic that is higher than necessary, improved the Irms characteristic by about 15%, and lowered the price as the size has become smaller, making it highly competitive in the market. do.

Sejin Eleccom Co., Ltd. is continuously accelerating development to produce products with excellent electrical characteristics and excellent price competitiveness.



< PQ2915 vs PQ2016 product comparison table >

Item

SPI-PQ2915HT-3R3

(NEW) SPI-PQ2016HT-3R3

Demension





Inductance

3.3uH

3.3uH

DCR (Max.)

1.86mΩ

1.3mΩ

Isat (Typ.)

67.0A

42.0A

Irms (Typ.)

30.0A

35.0A
